Backend
Space Segment / Payload
3x ML Models
Autonomous detection algorithms
Python in Docker
Containerized deployment
All Analysis On-Orbit
Real-time onboard processing
Alert Transmission
Telemetry stream to CROO server
Downlink Alert Stream
─────▶
Enterprise Server
Ground Segment / CROO
Database & Storage
Centralized event data store
REST API
Data access layer
Machine Logs
Telemetry & audit trails
Hosts UI WebApp
Serves web frontend
SPARTA Library
Aerospace cyber framework
WebSockets / HTTPS (Bi-dir)
◀─────▶
UI / Console
Operator Interface
Alert Dashboard
Real-time threat notification
Operator Interface
Interactive control panel
Operator Log Entry
Manual log & action record
Remediation Tracking
Incident resolution state
Intelligence Analysis
Forensic & threat profiling
